Add To InquiryModular Valve - MPC
shared:
| Model | Rated Pressure (kgf/cm²) | Rated Flow (L/min) | Weight (kg) |
| MPC-02 | 210 | 40 | 1.2 |
-
Series definition
MPC : Stacked one way valve -
Nominal diameter
02：1/4” ( Maximum working pressure 210 kg/cm² Maximum flow 40 L/min )
03：3/8” ( Maximum working pressure 210 kg/cm² Maximum flow 80 L/min )
-
Work port
A：A port
B：B port
W：Ab port
