Add To InquiryRelief Valve - SBSG
shared:
| Model | Max.Pressure (kg/cm²) | Pressure ADJ.Range (kg/cm²) | Max Flow (l/min) | Weight(kg) |
| SBSG-03_*_*_*_* | 250 |
1：8~70 2：8~140 3：8~250 |
100 | 4.8 |
| SBSG-06_*_*_*_* | 200 | 5.9 | ||
| SBSG-10_*_*_*_* | 400 | 11.3 |
| Model | Pressure ADJ.Range (kg/cm²) | Rated flow (l/min) | Weight(kg) |
| Sub-plate type | |||
| SBG-03G | 1：8~70 | 50 | 4.0 |
| SBG-06G | 2：8~210 | 125 | 5.0 |
| SBG-10G | 3：8~315 | 400 | 10.5 |
-
Series definition
SBG：Low noise relife valve
SBSG：Low noise eletromagnetic overflow valve
-
Nominal daimeter
03：3/8”
06：3/4”
10：1 1/4”
-
Installation
G：plate
T：With tubular
-
Pressure type
PN：The normally open type
NP：Normally closed type
-
Pressure range
1：8~70 kg/cm²
3：8~210 kg/cm²
4：8~315 kg/cm²
-
The handle direction
R：standard
L：Reverse type
